EAvision J70 Agricultural Drone
EAvision Australia
J70 Drone for Spraying, Spreading, Lifting and Mapping.
The EAvision J70 brings new capability for small to medium agricultural operators that require capacity to manage small to medium spraying and spreading requirements. With a maximum take-off weight of 110kg this medium drone will meet the needs of solo operators and small to medium sized jobs.
The J70 is the third in the “J” series of drones from EAvision and follows the successful J100 and J150. Many successful features have been incorporated and improved in the J70. EAvision’s demonstrated commitment to build quality in all EAvision Drones and the J70 is no exception. All major components are developed in-house and subject to a strict quality control process throughout every stage in the build process.
J70 Performance
The J70 comes with both larger motors and 56-inch propellers. Power output is rated at 10 grams per watt or 53 kg per motor. Overall performance retains the EAvision standard of 2 x Power to weight ratio.
New ECS/Motor interface and performance balancing software. Providing continuous, secure power efficiently and controlled to minimise heat build-up
Fusion Perception System
Advanced, automobile-grade, obstacle detection system. The J70 combines five advanced sensing modules to create a 360° terrain and obstacle environment, ensuring safe and efficient operation. Duel Forward LiDar, Dual Phased Array radar, and a 360 ° Millimetre Wave Radar provide sensing capability day and night. The Phased radar array also provides detection capability during dusty and/or foggy conditions.
Fish-eye FPV system
The J70 Fish-Eye fixed FPV camera offers a 160° field of view in both horizontal and vertical planes. The digital gymble provides a clear view of the operating environment with fewer moving parts, resulting in an increased overall reliability of the system.
The high-spec camera paired with the high transmission rate of the controller results in a better view with low latency.
CCMS Spray System
The J70 retains the rear four-nozzle layout that has been a proven success with the J100. The version 6 nozzles increase the max flow to 24lt/min when the four nozzles are in use. The current nozzle disc configuration has a droplet size range of 10 – 620 micron. Suitable for all spray applications.
New Auger – Spinner combination spreader
The J70 Spreader has a capacity of 70lts or 50kg uplift. The new combination of Auger and Spinner allows for smooth and constant product delivery with minimal blockages. The Auger design is compatible with both wet and dry fertilisers.
With a max flow rate of 240kg/min and an 8m swath, the spreading efficiency is greatly improved when combined with the maximum flight speed.
CTB Smart Battery
The J70 Smart battery maintains the same advanced modular design that has been successful with the J100. Already proving itself with superior performance, especially in hot environments and continual use.
Combined with a 9000 watt charger, the battery with its increased capacity of 29Ah provides long flight times and fast charging. Continuous operation with only 2 batteries is possible, even in our hot summer conditions.
The battery has many advanced features to improve both battery performance and self protection.
